WQV

WQV

الوصف الفني
· مضخات مياه الصرف الصحي الغاطسة القطع الجديدة
· مُجهزة بدفاعة من سبيكة دوامة مع 48HR (صلابة)
· أفضل الخصائص الهيدروليكية
· علبة المضخة من الحديد الزهر القوي الثقيل HT250
· غلاف مقاوم للتآكل وطويل الأمد
· محرك YE3 عالي الكفاءة ، مع حماية IP68 فئة F.
· عمود الدوران من الفولاذ المقاوم للصدأ AISI 304 أو الحديد المجلفن
· منفذ التفريغ بالمسامير والصواميل وأطواق التخمير
· جودة تحمل NSK ، ختم الميكانيكية مقاومة التآكل
3D PRODUCT CHAT NOW


NEW/NUEVO


TECHNICAL DESCRIPTION
· New cutting submersible sewage pumps
· Equipped with vortex alloy impeller with 48HR(hardness)
· Better hydraulic characteristics
· Pump case in heavy gauge robust cast iron HT250
· Casing resistant to abrasion and long-lasting
· YE3 high efficient motor, with protection IP68 class F
· Shaft in stainless steel AISI 304 or galvanized iron
· Discharge port with bolts,nuts and gastkets
· Quality NSK bearing, wear resistance mechanical seal


APPLICATIONS
· The WQV series pumps, manufactured from heavy gauge robust cast iron,resistant to abrasion and long-lasting, are equipped with a VORTEX impeller and are therefore suitable for draining dirty, filthy and refluent water,and water mixed with putrid mud. They are suitable for installation in sewers,tunnels,canal,
excavations,underground car parks,etc.


USING LIMITS
· Temperature of the liquid to +40 °C
· 10 m maximum immersion depth
· (with a sufficiently long power cable)
· Solids passage:
· from 25mm to 65mm





NEW/NUEVO


TECHNICAL DESCRIPTION
· New cutting submersible sewage pumps
· Equipped with vortex alloy impeller with 48HR(hardness)
· Better hydraulic characteristics
· Pump case in heavy gauge robust cast iron HT250
· Casing resistant to abrasion and long-lasting
· YE3 high efficient motor, with protection IP68 class F
· Shaft in stainless steel AISI 304 or galvanized iron
· Discharge port with bolts,nuts and gastkets
· Quality NSK bearing, wear resistance mechanical seal


USING LIMITS
· Temperature of the liquid to +40 °C
· 10 m maximum immersion depth
· (with a sufficiently long power cable)
· Solids passage:
· from 25mm to 65mm

APPLICATIONS
· The WQV series pumps, manufactured from heavy gauge robust cast iron,resistant to abrasion and long-lasting, are equipped with a VORTEX impeller and are therefore suitable for draining dirty, filthy and refluent water,and water mixed with putrid mud. They are suitable for installation in sewers,tunnels,canal,excavations,underground car parks,etc.
